Motivation: Building phylogenetic trees

The task for today will be to build a phylogenetic tree of 9 mammalian species using protein sequences

  • A phylogenetic tree is a tree showing evolutionary history of these species. Leaves are the present-day species, internal nodes are their common ancestors.
  • The input contains sequences of all proteins from each species (we will use only a smaller subset)
  • The process is typically split into several stages shown below

Identify ortholog groups

Orthologs are proteins from different species that “correspond” to each other. Orthologs are found based on sequence similarity and we can use a tool called blast to identify sequence similarities between pairs of proteins. The result of ortholog group identification will be a set of groups, each group having one sequence from each of the 9 species.

Align proteins on each group

For each ortholog group, we need to align proteins in the group to identify corresponding parts of the proteins. This is done by a tool called muscle

Unaligned sequences (start of protein O60568):

>human
MTSSGPGPRFLLLLPLLLPPAASASDRPRGRDPVNPEKLLVITVA...
>baboon
MTSSRPGLRLLLLLLLLPPAASASDRPRGRDPVNPEKLLVMTVA...
>dog
MASSGPGLRLLLGLLLLLPPPPATSASDRPRGGDPVNPEKLLVITVA...
>elephant
MASWGPGARLLLLLLLLLLPPPPATSASDRSRGSDRVNPERLLVITVA...
>guineapig
MAFGAWLLLLPLLLLPPPPGACASDQPRGSNPVNPEKLLVITVA...
>opossum
SDKLLVITAA...
>pig
AMASGPGLRLLLLPLLVLSPPPAASASDRPRGSDPVNPDKLLVITVA...
>rabbit
MGCDSRKPLLLLPLLPLALVLQPWSARGRASAEEPSSISPDKLLVITVA...
>rat
MAASVPEPRLLLLLLLLLPPLPPVTSASDRPRGANPVNPDKLLVITVA...

Aligned sequences:

rabbit       MGCDSRKPLL LLPLLPLALV LQPW-SARGR ASAEEPSSIS PDKLLVITVA ...
guineapig    MAFGA----W LLLLPLLLLP PPPGACASDQ PRGSNP--VN PEKLLVITVA ...
opossum      ---------- ---------- ---------- ---------- SDKLLVITAA ...
rat          MAASVPEPRL LLLLLLLLPP LPPVTSASDR PRGANP--VN PDKLLVITVA ...
elephant     MASWGPGARL LLLLLLLLLP PPPATSASDR SRGSDR--VN PERLLVITVA ...
human        MTSSGPGPRF LLLLPLLL-- -PPAASASDR PRGRDP--VN PEKLLVITVA ...
baboon       MTSSRPGLRL LLLLLLL--- -PPAASASDR PRGRDP--VN PEKLLVMTVA ...
dog          MASSGPGLRL LLGLLLLL-P PPPATSASDR PRGGDP--VN PEKLLVITVA ...
pig          AMASGPGLR- LLLLPLLVLS PPPAASASDR PRGSDP--VN PDKLLVITVA ...

Build phylogenetic tree for each group

For each alignment, we build a phylogenetic tree for this group. We will use a program called IQ-tree.

Example of a phylogenetic tree in newick format:

Tree for gene O60568 (note: this particular tree does not agree well with real evolutionary history)
 ((opossum:0.09636245,rabbit:0.85794020):0.05219782,
(rat:0.07263127,elephant:0.03306863):0.01043531,
(dog:0.01700528,(pig:0.02891345,
(guineapig:0.14451043,
(human:0.01169266,baboon:0.00827402):0.02619598
):0.00816185):0.00631423):0.00800806);

Build a consensus tree

The result of the previous step will be several trees, one for every group. Ideally, all trees would be identical, showing the real evolutionary history of the 9 species. But it is not easy to infer the real tree from sequence data, so the trees from different groups might differ. Therefore, in the last step, we will build a consensus tree. This can be done by using a tool called Phylip. The output is a single consensus tree.

Files and submitting

Our goal is to build a pipeline that automates the whole task using make and execute it remotely using qsub. Most of the work is already done, only small modifications are necessary.

  • Submit by copying requested files to /submit/make/username/
  • Do not forget to submit protocol, outline of the protocol is in /tasks/make/protocol.txt

Start by copying folder /tasks/make to your home folder

cp -ipr /tasks/make .
cd make

The folder contains three subfolders:

  • large: a larger sample of proteins for task A
  • tiny: a very small set of proteins for task B
  • small: a slightly larger set of proteins for task C

When you are done, you can submit all required files as follows (substitute your username):

cd ~/make
cp -ipvr protocol.txt large/queue.txt large/make.o* large/ref-end.blast tiny small /submit/make/your_username

# check what was submitted
ls -lr /submit/make/your_username

Task A (long job)

  • In this task, you will run a long alignment job (more than two hours).
  • Go to folder large, which contains the following files:
    • ref.fa: selected human proteins
    • other.fa: selected proteins from 8 other mammalian species
    • Makefile: runs blast on ref.fa vs other.fa (also formats database other.fa before that)
  • Run command the following command to see what commands will be done by make (you should see makeblastdb, blastp, and echo for timing):
    make -n > make-n.txt; cat make-n.txt
  • Run qsub with appropriate options (at least -cwd -b y) to run command make.
  • Then run the following to check the queue:
    qstat > queue.txt ; cat queue.txt
    • The output should show your jobs waiting in queue or running
  • When your job finishes, check the following files:
    • the output file ref.blast
    • standard output from the qsub job, which is stored in a file named e.g. make.oX where X is the number of your job. The output shows the time when your job started and finished (this information was written by commands echo in the Makefile)
  • Submit the following files:
    • File queue.txt showing your job waiting or running in the queue
    • File make.oX with output of your job
    • The last 100 lines from ref.blast under the name ref-end.blast (use tool tail -n 100)

Task B (finishing Makefile)

  • In this task, you will finish a Makefile for splitting blast results into ortholog groups and building phylogenetic trees for each group.
    • This Makefile works with much smaller files and so you can run it quickly many times without qsub
  • Work in folder tiny
    • ref.fa: 2 human proteins
    • other.fa: a selected subset of proteins from 8 other mammalian species
    • Makefile: a longer makefile
    • brm.pl: a Perl script for finding ortholog groups and sorting them to folders

The Makefile runs the analysis in four stages. Stages 1,2 and 4 are written in the Makefile, you have to finish stage 3.

  • If you run make without argument, it will attempt to run all 4 stages, but stage 3 will not run, because it is missing
  • Stage 1: run as make ref.brm
    • It runs blast as in task A, then splits proteins into ortholog groups and creates one folder for each group with file prot.fa containing protein sequences
  • Stage 2: run as make alignments
    • In each folder with an ortholog group, it will create an alignment prot.mfa.
  • Stage 3: run as make trees (needs to be written by you)
    • In each folder with an ortholog group, it should create files LG.treefile and JTT.treefile containing the results of the IQ-tree program run with two different evolutionary models LG and JTT+G4.
    • Create a rule that will create LG.treefile from prot.mfa in one gene folder. Use % for the folder name, similarly as in the rules to make alignments. Within the rule, you can use $* variable to get the name of this folder.
    • Run IQ-tree by commands of the form:
      iqtree2 -redo --seqtype AA -s GENE_FOLDER/prot.mfa -m LG -o opossum --seed 42 --prefix GENE_FOLDER/LG -n 50
    • Change GENE_FOLDER to the appropriate filename of the folder using make variables.
    • IQ-tree will create several output files starting with LG in the folder with the gene.
    • When this is done, create a similar rule except replace LG by JTT in the file names and change evolutionary model in the command by replacing -m LG option with -m JTT+G4.
    • Also add variables LG_TREES and JTT_TREES to the top of the Makefile listing filenames of all desirable trees and uncomment phony target trees which uses these variables.
  • Stage 4: run as make consensus
    • Output trees from stage 3 are concatenated for each model separately to files lg/intree, jtt/intree and then phylip is run to produce consensus trees lg.tree and jtt.tree
    • This stage also needs variables LG_TREES and JTT_TREES to be defined by you.
  • Run your Makefile and check that the files lg.tree and jtt.tree are produced, as well as their ASCII-art “images” lg.tree.txt and jtt.tree.txt.
  • Instructions for submitting see after Task C (you can submit B even if you do not do C).

Task C (adding statistics to Makefile)

IQ-tree also produced files named LG.iqtree and JTT.iqtree in each gene folder. These contain various statistics about the run of the program. We want to compare these values across genes and models, so we want to extract them to two tables in csv format. Namely, we are interested in two lines from the *.iqtree files:

  • Line starting “Log-likelihood of the tree” which gives a (negative) number saying how well the data fit the model. Higher number means a better fit. We can compare these numbers to see which model fits the data better.
  • Line starting “Total CPU time used” which gives computation time in seconds. We can see if the computation time is different for different models.
  • Uncomment the line adding a new goal to the Makefile named stats.
  • This goal has two subgoals producing files stats-time.tsv and stats-likelihood.tsv.
  • Write a rule for each of these subgoals producing the desired file.

To gather appropriate lines from all files and also know which file they come from, you can use grep command of the form
grep --with-filename '^Log-likelihood of the tree:' gene_Q*/*.iqtree
Its output will look like this:

gene_Q6ZWJ1_human/JTT.iqtree:Log-likelihood of the tree: -4475.9510 (s.e. 121.3816)
gene_Q6ZWJ1_human/LG.iqtree:Log-likelihood of the tree: -4648.0902 (s.e. 130.9257)
gene_Q8WUG5_human/JTT.iqtree:Log-likelihood of the tree: -4097.1127 (s.e. 64.7212)
gene_Q8WUG5_human/LG.iqtree:Log-likelihood of the tree: -4144.8778 (s.e. 67.7092)

You should reformat the output to stats-likelihood.tsv that looks like this (the columns are separated with tabs "\t"):

Q6ZWJ1_human    JTT -4475.9510
Q6ZWJ1_human    LG  -4648.0902
Q8WUG5_human    JTT -4097.1127
Q8WUG5_human    LG  -4144.8778
  • To do reformatting, you can use perl one-liners or sed/awk directly in the Makefile or write your own script in Perl or Python and call it from Makefile.
  • If you write one-liners in Makefile, you have to replace $ with $$ (e.g. $$F[0] to get the first column in a Perl one-liner).

File stats-time.tsv should be similar, but it should contain time in seconds in the third column as below. Your time measurements may differ.

Q6ZWJ1_human    JTT 24.6512
Q6ZWJ1_human    LG  6.47912
Q8WUG5_human    JTT 28.7618
Q8WUG5_human    LG  7.47675

Submitting tasks B and C

  • Submit the whole folder tiny (using cp -ri tiny /submit/make/username/), including Makefile, scripts you wrote of task C (if any), all gene folders with tree files and the resulting combined trees and statistics files.

Task D (running make, final obersvations)

  • Copy your Makefile and any scripts you wrote in tasks B and C to folder small, which contains 9 human proteins and run make on this slightly larger set.
    • Again, run it without qsub, but it will take some time, particularly if the server is busy
  • Look at the two resulting trees (jtt.tree.txt, lg.tree.txt)
    • Note that the two children of each internal node are equivalent, so their placement higher or lower in the figure does not matter.
    • Do the two trees differ from each other? If yes, how?
    • Branches of the tree contain a number called support indicating in how many of the individual gene trees this branch was found. Higher support means more reliable branch. What is the highest and lowest support for a branch in each tree?
    • Do your trees differ from the accepted “correct tree” shown below? If yes, how?
  • Run make stats and look at the resulting tsv files.
    • Which model produced higher likelihoods?
    • Which model runs faster?
  • Write your observations to the protocol and submit the entire small folder.

The correct tree extracted from a larger tree at the UCSC genome browser:

                                          +-------human
                          +---------------|
                          |               +-------baboon
                  +-------|
                  |       |       +---------------rabbit
                  |       +-------|
                  |               |       +-------rat
          +-------|               +-------|
          |       |                       +-------guineapig
          |       |
  +-------|       |                       +-------pig
  |       |       +-----------------------|
  |       |                               +-------dog
  |       |
  |       +---------------------------------------elephant
  |
  +-----------------------------------------------opossum

Further possibilities

Here are some possibilities for further experiments, in case you are interested (do not submit these):

  • You could copy your extended Makefile to folder large and create trees for all ortholog groups in the big set.
    • This would take a long time, so submit it through qsub and only some time after the lecture is over to allow classmates to work on task A.
    • After ref.brm si done, programs for individual genes can be run in parallel, so you can try running make -j 2 and request 2 threads from qsub
  • IQ-tree also supports many other models (for more information, see documentation); you could try to play with those. Or run IQ-tree without -m when it tries to find the best model for your input.
  • We were looking at the trees in text mode but you can create nice figures of the trees using figtree program. It is available on vyuka, but you can also install it on your computer if interested.
  • Command touch FILENAME will change the modification time of the given file to the current time.
    • What happens when you run touch on some of the intermediate files in the analysis in task B? Does Makefile always run properly?
